1255mm Wheel Modified Underbone Motorcycle 78km/H Commuter Motorcycle

200
MOQ
350$
Price
1255mm Wheel Modified Underbone Motorcycle 78km/H Commuter Motorcycle
Features Gallery Product Description Chat Now
Features
Specifications
Engine Type: Single-cylinder, Horizontal, Air-cooled
Displacement: 107 Cc
Max. Power: 5.2 KW @ 8,000 ± 500 Rpm
Max. Torque: 7.2 N·m @ 5,000 ± 500 Rpm
Transmission: 4-speed, Semi-automatic Clutch
Front Suspension: Telescopic Hydraulic Fork
Highlight:

1255mm wheel Underbone Motorcycle

,

commuter motorcycle 78km/h

,

78km/h modified underbone motorcycle
Basic Infomation
Place of Origin: CHINA
Brand Name: ZFYC
Model Number: XY1-B
Payment & Shipping Terms
Packaging Details: CKD,SKD,CBU
Delivery Time: 5-12 weeks
Payment Terms: L/C,T/T
Supply Ability: 1000Unit/Month
Product Description
Versatile 107cc Motorcycle
Versatile 107cc Motorcycle with 2.50-17 Front Tire & 2.75-16 Rear Tire, Aluminum Rear Carrier, Equipped Center Carrier
This versatile motorcycle features a 2.50-17 front tire and 2.75-16 rear tire configuration, complemented by aluminum rear and center carriers for enhanced utility. The chain final drive system ensures simple, reliable operation with precisely matched primary and final reduction ratios for optimal power transmission efficiency.
With a top speed of 78km/h and minimal maintenance requirements, this motorcycle delivers exceptional value for budget-conscious users seeking reliable performance and practical functionality.
Technical Specifications
Engine Type Single-cylinder, horizontal, air-cooled
Displacement 107 cc
Bore * Stroke 52.4 mm * 49.5 mm
Max. Power 5.2 kW @ 8,000 ± 500 rpm
Max. Torque 7.2 N*m @ 5,000 ± 500 rpm
Transmission 4-speed, semi-automatic clutch
Starting System Electric & kick start
Drive System Ratios
Primary Reduction Ratio 4.059
Final Reduction Ratio 2.714
1st Gear 3.273
2nd Gear 1.938
3rd Gear 1.35
4th Gear 1.043
Chassis & Dimensions
Front Tire 2.50-17 (M031 tread pattern)
Rear Tire 2.75-16 (M034 tread pattern)
Wheelbase 1255 mm
Seat Height 780 mm
Ground Clearance 140 mm
Net Weight 93 kg
Max. Load Capacity 150 kg
Performance & Capacity
Max. Speed 78 km/h
Climbing Ability ≥ 22°
Fuel Tank Capacity 3.1 L
Helmet Box Capacity Half-face helmet
Custom motorcycle orders accepted
