123.7cc Underbone Motorcycle Electric Kick Start Enduro Cross Bikes

100
MOQ
400$
Price
123.7cc Underbone Motorcycle Electric Kick Start Enduro Cross Bikes
Features Gallery Product Description Chat Now
Features
Specifications
Engine Type: Single-cylinder, Horizontal, Air-cooled
Displacement: 123.7 Cc
Max. Power: 6.3 KW @ 7,500 Rpm
Max. Torque: 8.8 N·m @ 5,500 Rpm
Front Suspension: Telescopic Hydraulic Fork
Rear Suspension: Dual Shock Absorbers
Highlight:

123.7cc Underbone Motorcycle

,

Electric Start enduro cross bikes

,

Kick Start enduro cross bike
Basic Infomation
Place of Origin: CHINA
Brand Name: ZFYC
Model Number: KUP-W
Payment & Shipping Terms
Packaging Details: CKD,SKD,CBU
Delivery Time: 5-12 weeks
Payment Terms: L/C,T/T
Supply Ability: 1000Unit/Month
Product Description
125cc Motorcycle Overview
125cc horizontal single-cylinder air-cooled engine motorcycle with electric & kick start, 4-speed semi-automatic clutch for easy operation, front and rear drum brakes for safety
This 123.7cc motorcycle features a horizontal single-cylinder air-cooled engine with electric and kick start capabilities. The 4-speed semi-automatic clutch ensures easy operation, while front and rear drum brakes provide reliable safety.
Engine Performance
Powered by a single-cylinder horizontal air-cooled engine delivering 6.3kW maximum power and 8.8N*m torque. Equipped with CDI ignition for stable performance and easy starting in any condition.
Technical Specifications
Engine Type Single-cylinder, horizontal, air-cooled
Bore * Stroke 54.0 mm * 54.0 mm
Displacement 123.7 cc
Compression Ratio 9.0 : 1
Max. Power 6.3 kW @ 7,500 rpm
Max. Torque 8.8 N*m @ 5,500 rpm
Ignition System CDI
Starting System Electric & kick start
Magneto 8-pole, full-wave AC
Transmission 4-speed, semi-automatic clutch
Final Drive Chain drive
Primary Reduction Ratio 4.06
1st Gear Ratio 2.833
2nd Gear Ratio 1.705
3rd Gear Ratio 1.238
4th Gear Ratio 0.958
Chassis & Suspension
Front Suspension Telescopic hydraulic fork
Rear Suspension Dual shock absorbers
Front Brake Drum brake
Rear Brake Drum brake
Front Tire 2.50-17 (standard tire)
Rear Tire 2.75-17 (standard tire)
Dimensions & Capacity
Overall Dimensions (L * W * H) 1900 * 720 * 1080 mm
Wheelbase 1260 mm
Seat Height 770 mm
Ground Clearance 140 mm
Net Weight 95 kg
Max. Load Capacity 150 kg
Fuel Tank Capacity 3.1 L
Helmet Box Capacity Full-face helmet
Performance & Electrical
Max. Speed 75 km/h
Climbing Ability ≥ 12°
Headlight Halogen bulb, 12V 35W (low beam 5W / high beam 12W)
Taillight Halogen bulb, 12V 21W / 5W
Front Turn Signals Halogen, 12V 10W
Rear Turn Signals Halogen, 12V 10W
Battery 12V 5Ah, maintenance-free gel battery
Optional Features
  • Front Wheel: Spoked wheel (optional aluminum wheel)
  • Rear Wheel: Spoked wheel (optional aluminum wheel)
  • Rear Carrier: Optional aluminum rear carrier
  • Center Carrier: Optional
Custom motorcycle orders accepted - Contact us for personalized configurations and special requirements.
