1920 X 720 X 1140mm Underbone Motorcycle Single Cylinder Engine Motorcycle

200
MOQ
350$
Price
1920 X 720 X 1140mm Underbone Motorcycle Single Cylinder Engine Motorcycle
Features Gallery Product Description Chat Now
Features
Specifications
Engine Type: Single-cylinder, Horizontal, Air-cooled
Bore × Stroke: 52.4 Mm × 49.5 Mm
Displacement: 107 Cc
Max. Power: 5.2 KW @ 8,000 ± 500 Rpm
Front Wheel: Aluminum Wheel
Rear Wheel: Aluminum Wheel
Highlight:

1920 x 720 x 1140mm Underbone Motorcycle

,

black single cylinder engine motorcycle

,

white single cylinder engine motorcycle
Basic Infomation
Place of Origin: CHINA
Brand Name: ZFYC
Model Number: XY1-WN
Payment & Shipping Terms
Packaging Details: CKD,SKD,CBU
Delivery Time: 5-12 weeks
Payment Terms: L/C,T/T
Supply Ability: 2000Unit/Month
Product Description
107cc Single-Cylinder Motorcycle
Comfortable 107cc Single-Cylinder Motorcycle with 4-Speed Gear System (1st 3.273, 2nd 1.938, 3rd 1.35, 4th 1.043), 780mm Seat Height, Suitable for Riders of Different Heights
Designed for practicality and reliability, this comfortable 107cc motorcycle features a 4-speed gear system and 780mm seat height suitable for riders of different heights. With overall dimensions of 1920*720*1140mm, it's perfect for daily commuting, short-distance deliveries, and weekend trips.
Key Features
  • 107cc single-cylinder air-cooled engine with steady power output
  • 4-speed semi-automatic transmission with precise gear ratios
  • Electric and kick start systems for reliable starting
  • 780mm seat height accommodates various rider heights
  • Ample storage space including helmet box and carriers
  • Dual shock absorbers for comfortable riding
Technical Specifications
Engine Type Single-cylinder, horizontal, air-cooled
Displacement 107 cc
Max. Power 5.2 kW @ 8,000 ± 500 rpm
Max. Torque 7.2 N*m @ 5,000 ± 500 rpm
Transmission 4-speed, semi-automatic clutch
Gear Ratios 1st: 3.273, 2nd: 1.938, 3rd: 1.35, 4th: 1.043
Starting System Electric & kick start
Suspension Front: Telescopic hydraulic fork
Rear: Dual shock absorbers
Brakes Front & Rear: Drum brake
Tires Front: 2.50-17 (M031)
Rear: 2.75-16 (M034)
Wheels Aluminum wheels front and rear
Dimensions 1920 * 720 * 1140 mm (L * W * H)
Wheelbase 1255 mm
Seat Height 780 mm
Ground Clearance 140 mm
Net Weight 93 kg
Max. Load Capacity 150 kg
Max. Speed 78 km/h
Fuel Capacity 3.1 L
Storage Helmet box (half-face helmet), aluminum rear carrier, center carrier
Custom motorcycle orders accepted - Contact us for personalized specifications
