Home /Products/Underbone Motorcycle/7500r/Min Beginner Commuter Motorcycle Single Cylinder Adventure Bikes

7500r/Min Beginner Commuter Motorcycle Single Cylinder Adventure Bikes

100
MOQ
350$
Price
7500r/Min Beginner Commuter Motorcycle Single Cylinder Adventure Bikes
Features Gallery Product Description Chat Now
Features
Specifications
Engine Type: Single-cylinder, Horizontal, Air-cooled
Displacement: 107 Cc
Max. Power: 5.2 KW @ 8,000 ± 500 Rpm
Transmission: 4-speed, Semi-automatic Clutch (with Top Gear Protection)
Front Brake: Disc Brake
Rear Brake: Drum Brake
Highlight:

7500r/min beginner commuter motorcycle

,

8000r/min beginner commuter motorcycle

,

5200w single cylinder adventure bikes
Basic Infomation
Place of Origin: CHINA
Brand Name: ZFYC
Model Number: XY2-B
Payment & Shipping Terms
Packaging Details: CKD,SKD,CBU
Delivery Time: 5-12 weeks
Payment Terms: L/C,T/T
Supply Ability: 1000 Unit/Month
Product Description
107cc Horizontal Single-Cylinder Motorcycle
107cc Horizontal Single-Cylinder Air-Cooled Motorcycle, Electric & Kick Start, 4-Speed Semi-Automatic Clutch, Front Disc Rear Drum Brake, Lightweight Fuel-Efficient, Max Speed 78km/h
This 107cc horizontal single-cylinder air-cooled motorcycle is engineered for efficient urban commuting. Featuring both electric and kick start options with a 4-speed semi-automatic clutch for simplified operation. Equipped with front disc and rear drum brakes, telescopic hydraulic fork, and dual rear shock absorbers for stable, comfortable riding. Lightweight design at only 93kg offers excellent fuel efficiency with a maximum speed of 78km/h.
Key Features
  • 107cc horizontal single-cylinder air-cooled engine
  • Electric & kick start system
  • 4-speed semi-automatic clutch with top gear protection
  • Front disc brake and rear drum brake
  • Telescopic hydraulic fork and dual rear shock absorbers
  • Lightweight construction - only 93kg
  • Excellent fuel efficiency
  • Maximum speed: 78km/h
  • Climbing ability: ≥22°
  • Load capacity: 150kg
  • Perfect for daily commuting and short trips
Technical Specifications
Engine Type Single-cylinder, horizontal, air-cooled
Bore * Stroke 52.4 mm * 49.5 mm
Displacement 107 cc
Compression Ratio 9.1 : 1
Max. Power 5.2 kW @ 8,000 ± 500 rpm
Max. Torque 7.2 N*m @ 5,000 ± 500 rpm
Ignition System CDI
Starting System Electric & kick start
Transmission 4-speed, semi-automatic clutch
Final Drive Chain drive
Front Suspension Telescopic hydraulic fork
Rear Suspension Dual shock absorbers
Front Brake Disc brake
Rear Brake Drum brake
Front Tire 2.50-17 (M031 tread pattern)
Rear Tire 2.75-16 (M034 tread pattern)
Overall Dimensions 1920 * 720 * 1140 mm
Wheelbase 1255 mm
Seat Height 780 mm
Ground Clearance 140 mm
Net Weight 93 kg
Max. Load Capacity 150 kg
Fuel Tank Capacity 3.1 L
Helmet Box Capacity Half-face helmet
Battery 12V 5Ah, maintenance-free
Custom motorcycle orders accepted - contact us for personalized specifications
